Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, dystrykt Fenghua, miasto Ningbo, prowincja Zhejiang, Chiny | airwolf@flyautomatic.com |
Miejsce pochodzenia: | Chiny |
Nazwa handlowa: | FESTO |
Numer modelu: | DGC-12-600 - GPA |
Minimalne zamówienie: | 1 szt |
---|---|
Cena: | EXW USD300-400 |
Szczegóły pakowania: | Plastikowa torba, karton |
Czas dostawy: | 7-10 dni roboczych |
Zasady płatności: | T/T, Western Union, Paypal |
Możliwość Supply: | 20 SZT miesięcznie |
Typ: | DGC-12-600 - GPA | Nr części: | 530907 |
---|---|---|---|
Marka: | FESTO | Średnica tłoka: | 12 mm |
Pozycja montażu: | Opcjonalny | Uszczelnienia materiałowe: | POM TPE-U(PU) |
High Light: | Linear Drive Double Acting Pneumatic Cylinder,530907 Pneumatic Air Cylinders,12mm Piston Pneumatic Air Cylinders |
About product
Basic design, plain or ball bearing guide, guide axis without actuator
All settings accessible from one side
Available with variable end stops and intermediate position module
Compact – installation length relative to stroke
Loads and devices can be directly mounted on the slide
Long strokes with no restrictions
Virtually no leakage
Technical Data
Piston diameter | 12 mm |
Mounting position | optional |
Guide | Basic guide Recirculating ball bearing guide |
Position detection | Via proximity switch |
Operating pressure | 0.25 MPa ... 0.8 MPa |
Operating pressure | 2.5 bar ... 8 bar |
Mode of operation | Double-acting |
Corrosion resistance class CRC | 1 - Low corrosion stress 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Type of mounting | With accessories |
Note on materials | RoHS-compliant |
Material cover | Wrought aluminium alloy |
Material seals | POM TPE-U(PU) |
Package picture
A wide range of products with excellent prices. Please hurry to me!
