Name: MCJA-11-12-5 MCJA-11-12-10 MCJA-11-12-15 MCJA-11-12-20 Mindman Double acting Compact Cylinder
Brand: Airwolf Automation
SKU: MCJA-11-12-5, MCJA-11-12-10, MCJA-11-12-15, MCJA-11-12-20
Price: 34.00 USD
Availability: InStock

Dom Produkty Cylindry pneumatyczne Air

MCJA-11-12-5 MCJA-11-12-10 MCJA-11-12-15 MCJA-11-12-20 Mindman Double acting Compact Cylinder

Szczegóły Produktu:

Miejsce pochodzenia:	Tajwan, Chiny
Nazwa handlowa:	Mindman, AIRWOLF or OEM
Orzecznictwo:	CE, ISO9001
Numer modelu:	MCJA-11-12-5, MCJA-11-12-10, MCJA-11-12-15, MCJA-11-12-20

Zapłata:

Minimalne zamówienie:	1 sztuka
Cena:	5-63USD
Szczegóły pakowania:	Pudła, kartony, palety, torby plastikowe
Czas dostawy:	1-7 dni roboczych
Zasady płatności:	T/T, Western Union, PayPal
Możliwość Supply:	1000 szt. tygodniowo

Kontakt

Szczegółowy opis produktu

Kod przedmiotu:	MCJA-11-12-5, MCJA-11-12-10, MCJA-11-12-15, MCJA-11-12-20	Materiał korpusu:	Stop aluminium
Materiał uszczelnienia tłoka:	NBR	Ciśnienie robocze:	0,05 ~ 1 MPa
Temperatura pracy:	-5 ~ + 60 ℃ (bez zamrażania)	Środek roboczy:	Powietrze
Rozmiar otworu:	12mm	Funkcjonować:	Podwójne aktorstwo
Podkreślić:	Mindman double acting pneumatic cylinder , Compact air cylinder with warranty , MCJA series pneumatic actuator

MCJA-11-12-5 MCJA-11-12-10 MCJA-11-12-15 MCJA-11-12-20 Mindman Double acting Compact Cylinder

The Mindman MCJA Series is a line of ultra-compact, lightweight pneumatic cylinders built for machinery where installation space is at a premium, offering both single-acting and double-acting configurations across a practical bore-size range so engineers can specify the right force without oversizing the footprint. Its low-profile body keeps the actuator flush with adjacent components, making it a natural fit for tandem or closely packed cylinder layouts where a standard ISO-profile cylinder would simply not fit.

Order Codes:

Item Code	Piston (mm)	Stroke (mm)	Type
MCJA-11-12-5	12	5	Double acting
MCJA-11-12-10	12	10	Double acting
MCJA-11-12-15	12	15	Double acting
MCJA-11-12-20	12	20	Double acting

Specification:

Model		MCJA
Acting type		Double acting / Single acting							Double acting
Tube I.D. (mm)		12	16	20	25	32	40	50	63	80	100
Port size		M5×0.8				Rc1/8		Rc1/4			Rc3/8
Medium		Air
Operatingperssurerange (MPa)	Double acting	0.05~1		0.03~1		0.02~1
	Single acting	0.2~1		0.15~1		0.1~1			—
Proof pressure		1.5 MPa
Ambient temperature		-5°C~+60°C (No freezing)
Available speed range		50~500 mm/sec

Material:

MCJA-11-12-5 MCJA-11-12-10 MCJA-11-12-15 MCJA-11-12-20 Mindman Double acting Compact Cylinder

Dimensions:

MCJA-11-12-5 MCJA-11-12-10 MCJA-11-12-15 MCJA-11-12-20 Mindman Double acting Compact Cylinder
