Name: Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke
Brand: FLY AUTOMATION
SKU: P1F-S032MC-0025-0000 P1F-S040MC-0025-0000 P1F-S050MC-0025-0000 P1F-S063MC-0025-0000 P1F-S032MC-0040-
Price: 90.00 USD
Availability: InStock

Dom Produkty Cylindry pneumatyczne Air

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke

Szczegóły Produktu:

Miejsce pochodzenia:	CHINY JAPONIA
Nazwa handlowa:	Parker or OEM
Numer modelu:	P1F-S032MC-0025-0000 P1F-S040MC-0025-0000 P1F-S050MC-0025-0000 P1F-S063MC-0025-0000 P1F-S032MC-0040-

Zapłata:

Minimalne zamówienie:	1PC
Cena:	EXW USD15-165
Szczegóły pakowania:	plastikowa torba, karton, torba opp
Czas dostawy:	8-10 dni roboczych
Zasady płatności:	T/T, Western Union, PayPal
Możliwość Supply:	1200 szt. Miesięcznie

Kontakt

Szczegółowy opis produktu

Beczka cylindra:	Anodowany stop aluminium	Projekt:	Tłok Tłoczysko
Presja robocza:	0-10bar	Medium operacyjne:	Sprężone powietrze do ISO 8573-1: 2010 [7: 4: 4]
Uwaga na temat medium operacyjnego i pilotażowego:	Możliwe jest smarowane (w którym to przypadku zawsze będzie wymagana operacja smarowana))	Temperatura otoczenia:	-20 ° C-80 ° C.
Materiał tłokowy:	Stal wysokostopowa	Pieczęcie:	Poliuretan, guma nitrylowa i guma fluoroczna
Łożyska i czapka końcowa:	Aluminiowe aloy z kutego aluminium	Konstrukcje:	ISO 15552 Standard, VDMA 24364-B1/B2-L (kompatybilność w pomieszczeniu czystym), zgodny z ROHS
Podkreślić:	Parker ISO15552 pneumatic cylinder , double acting air cylinder 32-125mm , P1F pneumatic cylinder with warranty

Parker ISO15552 P1F Double acting pneumatic cylinder 32-125mm Bore 5-2000mm stroke -20°C to +80°C P1F-S032MC-0070-0000 P1F-S040MC-0080-0000 P1F-S050MC-0125-0000 P1F-S063MC-0150-0000

Order Codes:

P1F-S032MC-0025-0000	P1F-S040MC-0025-0000	P1F-S050MC-0025-0000	P1F-S063MC-0025-0000
P1F-S032MC-0040-0000	P1F-S040MC-0040-0000	P1F-S050MC-0040-0000	P1F-S063MC-0040-0000
P1F-S032MC-0050-0000	P1F-S040MC-0050-0000	P1F-S050MC-0050-0000	P1F-S063MC-0050-0000
P1F-S032MC-0060-0000	P1F-S040MC-0060-0000	P1F-S050MC-0060-0000	P1F-S063MC-0060-0000
P1F-S032MC-0070-0000	P1F-S040MC-0070-0000	P1F-S050MC-0070-0000	P1F-S063MC-0070-0000
P1F-S032MC-0075-0000	P1F-S040MC-0075-0000	P1F-S050MC-0075-0000	P1F-S063MC-0075-0000
P1F-S032MC-0080-0000	P1F-S040MC-0080-0000	P1F-S050MC-0080-0000	P1F-S063MC-0080-0000
P1F-S032MC-0100-0000	P1F-S040MC-0100-0000	P1F-S050MC-0100-0000	P1F-S063MC-0100-0000
P1F-S032MC-0125-0000	P1F-S040MC-0125-0000	P1F-S050MC-0125-0000	P1F-S063MC-0125-0000
P1F-S032MC-0130-0000	P1F-S040MC-0130-0000	P1F-S050MC-0130-0000	P1F-S063MC-0130-0000
P1F-S032MC-0135-0000	P1F-S040MC-0135-0000	P1F-S050MC-0135-0000	P1F-S063MC-0135-0000
P1F-S032MC-0140-0000	P1F-S040MC-0140-0000	P1F-S050MC-0140-0000	P1F-S063MC-0140-0000
P1F-S032MC-0150-0000	P1F-S040MC-0150-0000	P1F-S050MC-0150-0000	P1F-S063MC-0150-0000
P1F-S032MC-0160-0000	P1F-S040MC-0160-0000	P1F-S050MC-0160-0000	P1F-S063MC-0160-0000
P1F-S032MC-0200-0000	P1F-S040MC-0200-0000	P1F-S050MC-0200-0000	P1F-S063MC-0200-0000
P1F-S032MC-0250-0000	P1F-S040MC-0250-0000	P1F-S050MC-0250-0000	P1F-S063MC-0250-0000
P1F-S032MC-0320-0000	P1F-S040MC-0320-0000	P1F-S050MC-0320-0000	P1F-S063MC-0320-0000
P1F-S032MC-0400-0000	P1F-S040MC-0400-0000	P1F-S050MC-0400-0000	P1F-S063MC-0400-0000
P1F-S032MC-0500-0000	P1F-S040MC-0500-0000	P1F-S050MC-0500-0000	P1F-S063MC-0500-0000
P1F-S032MC-0600-0000	P1F-S040MC-0600-0000	P1F-S050MC-0600-0000	P1F-S063MC-0600-0000
P1F-S032MC-0700-0000	P1F-S040MC-0700-0000	P1F-S050MC-0700-0000	P1F-S063MC-0700-0000
P1F-S032MC-0750-0000	P1F-S040MC-0750-0000	P1F-S050MC-0750-0000	P1F-S063MC-0750-0000
P1F-S032MC-0800-0000	P1F-S040MC-0800-0000	P1F-S050MC-0800-0000	P1F-S063MC-0800-0000
P1F-S032MC-0900-0000	P1F-S040MC-0900-0000	P1F-S050MC-0900-0000	P1F-S063MC-0900-0000
P1F-S032MC-1000-0000	P1F-S040MC-1000-0000	P1F-S050MC-1000-0000	P1F-S063MC-1000-0000
P1F-S032MC-1100-0000	P1F-S040MC-1100-0000	P1F-S050MC-1100-0000	P1F-S063MC-1100-0000
P1F-S032MC-1200-0000	P1F-S040MC-1200-0000	P1F-S050MC-1200-0000	P1F-S063MC-1200-0000
P1F-S032MC-1300-0000	P1F-S040MC-1300-0000	P1F-S050MC-1300-0000	P1F-S063MC-1300-0000
P1F-S032MC-1400-0000	P1F-S040MC-1400-0000	P1F-S050MC-1400-0000	P1F-S063MC-1400-0000
P1F-S032MC-1500-0000	P1F-S040MC-1500-0000	P1F-S050MC-1500-0000	P1F-S063MC-1500-0000
P1F-S032MC-1600-0000	P1F-S040MC-1600-0000	P1F-S050MC-1600-0000	P1F-S063MC-1600-0000
P1F-S032MC-1700-0000	P1F-S040MC-1700-0000	P1F-S050MC-1700-0000	P1F-S063MC-1700-0000
P1F-S032MC-1800-0000	P1F-S040MC-1800-0000	P1F-S050MC-1800-0000	P1F-S063MC-1800-0000
P1F-S032MC-1900-0000	P1F-S040MC-1900-0000	P1F-S050MC-1900-0000	P1F-S063MC-1900-0000
P1F-S032MC-2000-0000	P1F-S040MC-2000-0000	P1F-S050MC-2000-0000	P1F-S063MC-2000-0000
P1F-S080MC-0025-0000	P1F-S100MC-0025-0000	P1F-S125MC-0025-0000
P1F-S080MC-0040-0000	P1F-S100MC-0040-0000	P1F-S125MC-0040-0000
P1F-S080MC-0050-0000	P1F-S100MC-0050-0000	P1F-S125MC-0050-0000
P1F-S080MC-0060-0000	P1F-S100MC-0060-0000	P1F-S125MC-0060-0000
P1F-S080MC-0070-0000	P1F-S100MC-0070-0000	P1F-S125MC-0070-0000
P1F-S080MC-0075-0000	P1F-S100MC-0075-0000	P1F-S125MC-0075-0000
P1F-S080MC-0080-0000	P1F-S100MC-0080-0000	P1F-S125MC-0080-0000
P1F-S080MC-0100-0000	P1F-S100MC-0100-0000	P1F-S125MC-0100-0000
P1F-S080MC-0125-0000	P1F-S100MC-0125-0000	P1F-S125MC-0125-0000
P1F-S080MC-0130-0000	P1F-S100MC-0130-0000	P1F-S125MC-0130-0000
P1F-S080MC-0135-0000	P1F-S100MC-0135-0000	P1F-S125MC-0135-0000
P1F-S080MC-0140-0000	P1F-S100MC-0140-0000	P1F-S125MC-0140-0000
P1F-S080MC-0150-0000	P1F-S100MC-0150-0000	P1F-S125MC-0150-0000
P1F-S080MC-0160-0000	P1F-S100MC-0160-0000	P1F-S125MC-0160-0000
P1F-S080MC-0200-0000	P1F-S100MC-0200-0000	P1F-S125MC-0200-0000
P1F-S080MC-0250-0000	P1F-S100MC-0250-0000	P1F-S125MC-0250-0000
P1F-S080MC-0320-0000	P1F-S100MC-0320-0000	P1F-S125MC-0320-0000
P1F-S080MC-0400-0000	P1F-S100MC-0400-0000	P1F-S125MC-0400-0000
P1F-S080MC-0500-0000	P1F-S100MC-0500-0000	P1F-S125MC-0500-0000
P1F-S080MC-0600-0000	P1F-S100MC-0600-0000	P1F-S125MC-0600-0000
P1F-S080MC-0700-0000	P1F-S100MC-0700-0000	P1F-S125MC-0700-0000
P1F-S080MC-0750-0000	P1F-S100MC-0750-0000	P1F-S125MC-0750-0000
P1F-S080MC-0800-0000	P1F-S100MC-0800-0000	P1F-S125MC-0800-0000
P1F-S080MC-0900-0000	P1F-S100MC-0900-0000	P1F-S125MC-0900-0000
P1F-S080MC-1000-0000	P1F-S100MC-1000-0000	P1F-S125MC-1000-0000
P1F-S080MC-1100-0000	P1F-S100MC-1100-0000	P1F-S125MC-1100-0000
P1F-S080MC-1200-0000	P1F-S100MC-1200-0000	P1F-S125MC-1200-0000
P1F-S080MC-1300-0000	P1F-S100MC-1300-0000	P1F-S125MC-1300-0000
P1F-S080MC-1400-0000	P1F-S100MC-1400-0000	P1F-S125MC-1400-0000
P1F-S080MC-1500-0000	P1F-S100MC-1500-0000	P1F-S125MC-1500-0000
P1F-S080MC-1600-0000	P1F-S100MC-1600-0000	P1F-S125MC-1600-0000
P1F-S080MC-1700-0000	P1F-S100MC-1700-0000	P1F-S125MC-1700-0000
P1F-S080MC-1800-0000	P1F-S100MC-1800-0000	P1F-S125MC-1800-0000
P1F-S080MC-1900-0000	P1F-S100MC-1900-0000	P1F-S125MC-1900-0000
P1F-S080MC-2000-0000	P1F-S100MC-2000-0000	P1F-S125MC-2000-0000

HOW TO ORDER:

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke

Datasheet:

Product type Standard cylinder according to ISO 15552
Bore size 32 - 125 mm
Stroke length 5 - 2000 mm
Versions Double acting
Cushioning Adjustable air cushioning
Position sensing Proximity sensor
Installation ISO cylinder and piston rod mountings

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke
